StarTech.com 2x2 HDMI Video Wall Controller - 4K 60Hz HDMI 2.0 Video Input to 4x 1080p Output - Video Wall Processor for Multi Screen Display - Video Wall Splitter - RS232/Ethernet Control - TAA
Stock: 212 units
StarTech.com 2x2 HDMI Video Wall Controller - 4K 60Hz HDMI 2.0 Vide...
Description
Description
Product overview
4K Video Wall Splitter | HDMI 2.0 | 1 Input 4 Outputs | 2-Year Warranty This video wall controller lets you connect your HDMI video source to multiple HDMI displays, with support for Ultra HD resolutions and 7.1 surround sound audio. You can use the controller as a video splitter to distribute the same HDMI signal to four displays or you can combine your video source across four displays to create a 2x2 video wall. Supports True 4K at 60Hz Not all 2x2 video wall matrix controllers are created equal. While some HDMI 1.4 video wall controllers can achieve 4K resolutions, they'll only work at a 30Hz refresh rate. This 4K 60Hz HDMI video wall processor offers full support for HDMI 2.0, including true 4K resolution at 60Hz. Widely Compatible The HDMI video wall splitter supports HDCP 2.2 and is backward compatible with 4K 30Hz and 1080p displays. This ensures that it will work with lower resolution displays such as TVs around your site or in your digital signage application. Easy Installation and Setup For hassle-free setup, the 4K HDMI splitter offers easy plug-and-play installation. Simply connect your source and 4 displays and the 4k video wall splitter will automatically create a video wall at the appropriate resolution. The Choice of IT Pros Since 1985 StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to IT Professionals. Our local StarTech.com Technical Advisors have broad product expertise and work directly with our StarTech.com Engineers to...
Why choose the StarTech.com 2x2 HDMI Video Wall Controller - 4K 60Hz HDMI...?
The StarTech.com 2x2 HDMI Video Wall Controller - 4K 60Hz HDMI 2.0 Video... is a video switches from StarTech.com, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Video port type: HDMI; HDMI version: 2.0; HDMI in: 1. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Video port type | HDMI |
| HDMI version | 2.0 |
| HDMI in | 1 |
| Number of HDMI outputs | 4 |
| USB port type | USB Type-A |
| RJ-45 input ports | 1 |
| RS-232 ports | 1 |
| DC-in jack | Yes |
| Material | Metal |
| Product colour | Black |
| Extended display identification data (EDID) | Yes |
| HDCP | Yes |
| Maximum refresh rate | 60 Hz |
| Supported graphics resolutions | 4096 x 2160 |
| LED indicators | Yes |
| Audio output channels | 7.1 channels |
| HDCP version | 2.2 |
| AC input voltage | 100 - 240 V |
| AC adapter input current | 1 A |
| AC adapter output voltage | 24 V |
| AC adapter output current | 1.25 A |
| Certification | CE, FCC, REACH |
| Width | 165 mm |
| Depth | 230 mm |
| Height | 45 mm |
| Weight | 1 kg |
| Package width | 263 mm |
| Package depth | 302 mm |
| Package height | 70 mm |
| Package weight | 1.6 kg |
| Manual | Yes |
| AC adapter included | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Compliance certificates | RoHS |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 318 mm |
| Master (outer) case length | 550 mm |
| Master (outer) case height | 380 mm |
| Brand | StarTech.com |
| Manufacturer part number | ST124HDVW |
| GTIN / UPC | ['0065030883603', '065030883603'] |
