StarTech.com 4 Port PCI Express 2.0 SATA III 6Gbps RAID Controller Card with HyperDuo SSD Tiering - TAA
Stock: 428 units
StarTech.com 4 Port PCI Express 2.0 SATA III 6Gbps RAID Controller ...
Description
Description
Product overview
Add 4 Internal SATA III (6Gbps) ports to a computer through a PCI Express x2 slot The PEXSAT34RH 4-Port PCI Express 2.0 SATA Controller Card with HyperDuo adds 4 AHCI SATA III ports to a computer through a PCIe slot (x2), delivering multiple internal 6Gbps connections for high-performance hard drives and Solid State Drives (SSDs). Featuring HyperDuo technology, the SATA card offers SSD auto-tiering which lets you balance the performance advantages of SSD storage with the cost-effectiveness and large capacity of standard hard drives. By combining SSD and HDD drives into a single volume (up to 3 SSD + 1 HDD), HyperDuo discreetly works in the background to identify and move frequently accessed files to the faster SSD drive(s) for improved data throughput - up to 80% of SSD performance! (Note: The HyperDuo automatic storage tiering feature is compatible with computers that use a BIOS.) The PCIe SATA controller card supports Port Multiplier (PM), enabling multiple SATA drives to be connected to one port over a single cable, for a total of 7 drives (Up to 4 drives through PM on one port, and a single drive to the remaining 3 ports). Plus, the SATA controller card offers an effective hardware RAID solution, with native RAID (0, 1, 1+0) support. Drives Used: SSD: OCZ Vertex 3 Series 2.5” 120 GB (VTX3-25SAT3-120G) HDD: Western Digital Caviar Green 3.5” 2 TB (WD20EARS) Software Used: IO Meter, 256KB Sequential Read, queue depth = 10 This PCIe SATA 6gbps card is backed by a 2-year StarTech.com warranty and free lifetime technical support.
Why choose the StarTech.com 4 Port PCI Express 2.0 SATA III 6Gbps RAID...?
The StarTech.com 4 Port PCI Express 2.0 SATA III 6Gbps RAID Controller... is a raid controllers from StarTech.com, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Supported storage drive interfaces: Serial ATA, Serial ATA III; Host interface: PCI Express; PCI Express slots version: 2.0. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Backups and archiving
- Workstation performance upgrades
- Media and creative workflows
- Server and NAS capacity expansion
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Supported storage drive interfaces | Serial ATA, Serial ATA III |
| Host interface | PCI Express |
| PCI Express slots version | 2.0 |
| Internal SATA ports quantity | 4 |
| RAID levels | 0, 1, 10, JBOD |
| Data transfer rate | 6 Gbit/s |
| SSD support | Yes |
| Chipset | Marvell - 88SE9230 |
| Logical block addressing (LBA) support | 48 bit |
| Sustainability compliance | Yes |
| Compliance certificates | CE, RoHS |
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64... |
| Mac compatibility | Yes |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9... |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Operating temperature (T-T) | 5 - 50 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Width | 120 mm |
| Depth | 70 mm |
| Height | 20 mm |
| Weight | 49 g |
| Package width | 144 mm |
| Package depth | 174 mm |
| Package height | 30 mm |
| Package weight | 141 g |
| Master (outer) case width | 382 mm |
| Master (outer) case length | 498 mm |
| Master (outer) case height | 322 mm |
| Products per master (outer) case | 60 pc(s) |
| Harmonized System (HS) code | 84733080 |
| Manual | Yes |
| Drivers included | Yes |
| PCI Card form factor | Full-height (low-profile) |
| Brand | StarTech.com |
| Manufacturer part number | PEXSAT34RH |
| GTIN / UPC | ['0065030849951', '065030849951', '0731215166419', '731215166419'] |
