ASUS ASUS-PRO-WS-2200P power supply unit 2200 W 20+4 pin ATX ATX Black
Stock: 4 units
ASUS ASUS-PRO-WS-2200P power supply unit 2200 W 20+4 pin ATX ATX Black
Description
Description
Product overview
ASUS Pro WS 2200W Platinum PSU delivers exceptional voltage stability and advanced power delivery for professionals, supporting up to four graphics cards to meet the demanding AI workloads. The ASUS Pro WS 2200W Platinum PSU is engineered to support up to four GeForce RTX™ 5080 graphics cards. It also features 80 PLUS Platinum certification, high-performance copper pins, dual-ball fan bearings, etched cables, rock-solid voltage stability and advanced power delivery, making it an ideal choice for AI solutions, deep learning and IT management. ENGINEERING. Heavy-Duty Power. Designed to reliably deliver the thousands of watts necessary to power up to four NVIDIA® GeForce RTX™ 5080 graphics cards, the ASUS Pro WS 2200W Platinum enables breakthrough performance that meets the needs of demanding AI workloads. Gold-Plated High-Performance Copper Pins. The copper pins of the PCIe® connectors in this PSU have been upgraded with gold plating to help ensure cooler operation and improved power delivery efficiency. This plating translates to a significant reduction in normal 12V-2x6 connector temperatures (up to 10°C), promoting optimal performance and stability for even the most demanding graphics cards. Furthermore, the improved contact between socket pins and connectors reduces resistance and improves durability for connector insertion and removal, ensuring reliable cooling performance. Protective PCB Coating. All wrapped up. A protective conformal coating envelops the circuit board to help protect against short-circuits caused by moisture, dust or debris. This added layer of...
Why choose the ASUS ASUS-PRO-WS-2200P power supply unit 2200 W 20+4 pin...?
The ASUS ASUS-PRO-WS-2200P power supply unit 2200 W 20+4 pin ATX ATX Black is a power supply units from ASUS, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Total power: 2200 W; AC input voltage: 200 - 240 V; Power Factor Correction (PFC) type: Active. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Workstation and mobile device charging
- Point-of-sale and kiosk equipment
- Network closets and edge devices
- Field and remote work kits
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Total power | 2200 W |
| AC input voltage | 200 - 240 V |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 130 W |
| Combined power (+12V) | 2200 W |
| Combined power (+5V) | 130 W |
| Combined power (-12V) | 9.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 25 A |
| Max output current (+12V) | 183.3 A |
| Max output current (+5V) | 25 A |
| Max output current (-12V) | 0.8 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 92% |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 61 cm mm |
| Number of SATA power connectors | 12 |
| SATA power cable length | 120,400 mm |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| Peripheral (Molex) power cable length | 150,400 mm |
| PCI Express power connectors (6+2 pin) | 4 |
| PCI Express power connectors (16-pin) | 4 |
| PCI Express power cable length | 75 cm mm |
| CPU power connector (4+4 pin) | Yes |
| CPU power cable length | 100 cm mm |
| ATX power connector (20+4 pin) | Yes |
| Cabling type | Fully-Modular |
| 80 PLUS certification | 80 PLUS Platinum |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| Bearing technology | Ball bearing |
| Product colour | Black |
| Cooling type | Active |
| On/off switch | Yes |
| Compliance certificates | RoHS |
| Width | 150 mm |
| Depth | 175 mm |
| Height | 86 mm |
| Brand | ASUS |
| Manufacturer part number | 90YE00Z1-B0AA00 |
| GTIN / UPC | ['4711387972939', '0197105972933', '197105972933'] |
