ATEN VM5808HA matrix switcher AV matrix switcher 58.1 W
Stock: 0 units
Description
Description
Product overview
The 8 x 8 HDMI Matrix Switch allows any of the 8 HDMI input signals to be routed to any of the 8 HDMI output channels with no compromise on flexibility. Multiple methods are available when it comes to controlling the device, such as through the front panel pushbuttons, RS-232, and Ethernet (Telnet / Web GUI) connections. Plus, the VM5808HA supports ATEN Video Matrix Control app for device status viewing and controlling. It can also be integrated with ATEN Control System, a platform where Ethernet-based ATEN Video Matrix Switches and third-party devices (such as projectors, lights, AV devices) are centrally monitored, managed, and controlled. Signal management is made efficient with the front panel LCD, giving users a quick view of all port connections. In addition, the local HDMI output port allows real-time monitoring of multiple sources on a single display exactly where the Matrix Switch is located. As the ultimate video wall solution, the FPGA-based VM5808HA features ATEN's exclusive Seamless Switch technology, ensuring uninterrupted video streams, real-time control, and stable signal transmission. The built-in scaler automatically scales any input video feed to match the native resolution of the output display for the best video and picture quality. To prevent screen tearing, the VM5808HA adopts FrameSync technology to synchronize the scaler output frame rates to the input signal frame rates, guaranteeing stunning tear-free video walls. Speaking of audio functionality, the Matrix Switch features audio de-embedding, enabling digital audio from any HDMI input to be...
Why choose the ATEN VM5808HA matrix switcher AV matrix switcher 58.1 W?
The ATEN VM5808HA matrix switcher AV matrix switcher 58.1 W is a matrix switchers from ATEN, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Product type: AV matrix switcher; Data transfer rate: 6.75 Gbit/s; Maximum pixel clock: 225 MHz. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Product type | AV matrix switcher |
| Data transfer rate | 6.75 Gbit/s |
| Maximum pixel clock | 225 MHz |
| Maximum resolution | 1920 x 1080 pixels |
| HDCP | Yes |
| HDCP version | 1.4 |
| 3D | Yes |
| Firmware upgradeable | Yes |
| Extended display identification data (EDID) | Yes |
| Supported resolutions | 640 x 480 @ 60/72/75 Hz 1280 x 720p 60 Hz (16:9) 800 x 600 @ 56/60/72/75 Hz 1920 x 1080i 60 Hz (16:9) 1024 x 768 @ 60/70/75 Hz 1920 x 1080p 60 Hz (16:9) 1280 x 800 @ 60 Hz 720 x 576p 50 Hz (4:3) / (16:9) 1280 x 1024... |
| Housing colour | Black |
| Housing material | Metal |
| Rack mounting | Yes |
| Rack capacity | 1U |
| On/off switch | Yes |
| HDMI input ports quantity | 8 |
| HDMI output ports quantity | 9 |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 ports | 1 |
| Audio (L/R) out | 1 |
| Power consumption (max) | 58.1 W |
| Power consumption (typical) | 56.6 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1 A |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Heat dissipation | 265 BTU/h |
| Heat dissipation (max) | 272 BTU/h |
| Country of origin | Taiwan |
| Width | 378.2 mm |
| Depth | 432.4 mm |
| Height | 44 mm |
| Weight | 5.54 kg |
| Cables included | AC |
| Rack mount kit | Yes |
| Manual | Yes |
| Brand | ATEN |
| Manufacturer part number | VM5808HA |
| GTIN / UPC | ['0672792013942', '672792013942'] |
