StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter - TAA
Stock: 54 units
StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter - TAA
Description
Description
Product overview
Build a RAID array with two mSATA SSDs that can be installed into a single 2.5in SATA bay Vastly increase system performance by adding a dual mSATA SSD RAID array into any 2.5" SATA HDD application with the 25SAT22MSAT mSATA to SATA adapter. Utilize the full potential of your SATA III controller, with mSATA SSDs reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps. mSATA SSDs also save you money by reducing your power consumption over regular platter drives. You can achieve greater SSD capacity, or data redundancy with the Dual SSD controller supporting multiple RAID modes (RAID 0, 1, BIG). The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another. Help protect the health of your drive with an open-frame design ensuring maximum heat dissipation. The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and lifetime technical support.
Why choose the StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter...?
The StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter - TAA is a interface cards/adapters from StarTech.com, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Host interface: SATA; Output interface: mSATA; SATA revision: 3.0. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Desk setups and docking stations
- AV and presentation systems
- IT deployments and refresh projects
- Server room and rack cabling
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Host interface | SATA |
| Output interface | mSATA |
| SATA revision | 3.0 |
| Port multiplier | Yes |
| Internal | Yes |
| Product colour | Black, Green |
| Mean time between failures (MTBF) | 5101299 h |
| Certification | CE, FCC |
| Chipset | JMicron JMS562 |
| Data transfer rate (max) | 6 Gbit/s |
| RAID levels | 0, 1, BIG, JBOD |
| Plug and Play | Yes |
| Operating temperature (T-T) | -40 - 85 °C |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Compliance certificates | RoHS |
| Width | 70 mm |
| Depth | 97 mm |
| Height | 7 mm |
| Weight | 39 g |
| Mounting brackets included | Yes |
| Quick installation guide | Yes |
| Package width | 143 mm |
| Package depth | 175 mm |
| Package height | 34 mm |
| Package weight | 107 g |
| Harmonized System (HS) code | 84733020 |
| Products per master (outer) case | 60 pc(s) |
| Master (outer) case width | 382 mm |
| Master (outer) case length | 498 mm |
| Master (outer) case height | 322 mm |
| Brand | StarTech.com |
| Manufacturer part number | 25SAT22MSAT |
| GTIN / UPC | ['0065030855617', '065030855617', '0650308556176', '650308556176', '0758399106024', '758399106024'] |
