StarTech.com HDMI over IP Extender Kit with Video Wall Support - 1080p - TAA
Stock: 50 units
StarTech.com HDMI over IP Extender Kit with Video Wall Support - 10...
Description
Description
Product overview
HDMI® Video over Cat5e or Cat6 |Multiple Sources to Multiple Displays | Mobile Control App This HDMI over IP extender kit distributes video to a remote location, over your local area network (LAN) and Cat5e or Cat6 Ethernet cabling. By combining this kit with additional receivers (sold separately) and an Ethernet switch (sold separately) you can distribute an HDMI source to multiple locations and create video walls using several remote displays and receivers in the same location. You can also use multiple transmitters on the same network to distribute different video sources or connect the transmitter directly to a receiver at up to 330 ft. (100 m), in a point-to-point setup. Remote control of serial devices is supported through RS-232 extension. Resolutions up to 1080p, with Audio With support for video resolutions up to 1080p (1920 x 1080 at 60Hz), the transmitter also supports digital and analog audio to the receiver and analog audio from the receiver to the transmitter. Mobile Control Through a Free App The kit includes an easy-to-use online app to manage your IP video distribution. The app is available on iOS for an iPhone or iPad, and Android for a smartphone or tablet. Download the StarTech.com Video Control software to manage your IP video distribution. NOTE: Your router must support IGMP snooping. Please refer to your network switch or router documentation to ensure IGMP snooping is supported and enabled. Hassle-Free Installations The HDMI transmitter/receiver kit includes optional shelf-mounting hardware. It uses Cat5e or Cat6 cables and works with existing...
Why choose the StarTech.com HDMI over IP Extender Kit with Video Wall...?
The StarTech.com HDMI over IP Extender Kit with Video Wall Support... is a av extenders from StarTech.com, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Type: AV transmitter & receiver; Maximum resolution: 1920 x 1080 pixels; Cable types supported: Cat5e, Cat6. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Desk setups and docking stations
- AV and presentation systems
- IT deployments and refresh projects
- Server room and rack cabling
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Type | AV transmitter & receiver |
| Maximum resolution | 1920 x 1080 pixels |
| Cable types supported | Cat5e, Cat6 |
| Maximum transfer distance | 100 m |
| Maximum refresh rate | 60 Hz |
| Audio output channels | 7.1 channels |
| LED indicators | Link, Network, Power, Status |
| Supported video modes | 720p, 1080p |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800, 1360 x 768 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080) |
| Rack mounting | Yes |
| Daisy chain | Yes |
| Rubber feet | Yes |
| Product colour | Black |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| Audio input | 2 x 3.5 mm |
| Audio output | 2 x 3.5 mm |
| RJ-11 ports quantity | 4 |
| 3.5 mm (1/8-inch) in | Yes |
| 3.5 mm (1/8-inch) out | Yes |
| AC input voltage | 100 - 240 V |
| Operating voltage | 12 V |
| Input current | 0.6 A |
| Output current | 1.5 A |
| Power consumption (typical) | 10 W |
| External power adapter | Yes |
| Power plug type | Type M |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Width | 118 mm |
| Depth | 131 mm |
| Height | 31 mm |
| Weight | 1.2 kg |
| Package width | 236 mm |
| Package depth | 366 mm |
| Package height | 76 mm |
| Package weight | 2.3 kg |
| Brand | StarTech.com |
| Manufacturer part number | ST12MHDLAN2K |
| GTIN / UPC | ['0065030878456', '065030878456'] |
