Intellinet Gigabit High-Power PoE+ Injector, 1 x 30 W, IEEE 802.3at/af Power over Ethernet (PoE+/PoE)
Stock: 0 units
Description
Description
Product overview
Reduce costs by using existing Cat5 cable to provide both power and data. The Intellinet Network Solutions 1-Port Gigabit High-Power PoE+ Injector allows you to connect your IEEE 802.3af/at-compliant products to a non-PoE LAN switch port. The PoE Injector can be used to connect a wireless access point, IP phone, network camera or any IEEE 802.3af/at-powered device (PD) to a switch. The device has an output power rating of up to 30 watts. That's enough for even power-hungry PoE devices. Reduce Wiring Costs. No need to run AC power lines for your wireless access point, network camera or IP phone. Simply connect the PoE Injector to the LAN switch port, and use the existing Cat5 cabling to deliver DC power as well as transfer data. Protect Your Equipment. Now that you are running DC power to your networked equipment through the Cat5e/6 cabling, you need to be sure that the products are protected from power problems. The PoE Injector was designed to protect equipment from short circuits (short GRND), current overloads and high voltages.
Why choose the Intellinet Gigabit High-Power PoE+ Injector, 1 x 30 W, IEEE...?
The Intellinet Gigabit High-Power PoE+ Injector, 1 x 30 W, IEEE... is a poe adapters from Intellinet, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Ethernet interface type: Gigabit Ethernet; Ethernet LAN data rates: 10,100,1000 Mbit/s; Cable types supported: Cat5, Cat5e. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| Cable types supported | Cat5, Cat5e |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | PoE, Power |
| Power protection features | Over voltage, Overload, Short circuit |
| Ethernet LAN (RJ-45) ports | 2 |
| Input voltage | 100 - 240 V |
| Power consumption (max) | 42 W |
| Compliance certificates | CE, RoHS, Federal Communications Commission (FCC) |
| Certification | FCC Class A Subpart B, CE, RoHS, UKCA, NDAA |
| Operating temperature (T-T) | 5 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -20 - 55 °C |
| Width | 72 mm |
| Depth | 154 mm |
| Height | 35 mm |
| Weight | 790 g |
| Number of products included | 1 pc(s) |
| Manual | Yes |
| Harmonized System (HS) code | 85044095 |
| Brand | Intellinet |
| Manufacturer part number | 560566 |
| GTIN / UPC | ['0070090134732', '070090134732', '0806294960095', '806294960095', '0766623560566', '766623560566'] |
Frequently asked questions
How long does delivery take?
Orders are processed within 24 hours. Once your tracking number is issued, delivery takes 24 to 72 hours to major centres in the main provinces, and 3 to 8 business days to remote regions. We ship with FedEx, DHL, UPS, Canada Post and Purolator.
Is this product covered by a warranty?
Yes. This item carries the manufacturer's warranty. See our Refund Policy for return windows and conditions, or contact us and we will walk you through the process.
Can I get volume pricing?
Yes. Volume discounts apply automatically as quantity increases, and our team can quote larger projects directly — reach us by phone, WhatsApp or email.
Do the specifications on this page come from the manufacturer?
They do. Product data on this page is sourced from the manufacturer's own catalogue, not rewritten from a distributor summary.
