Intellinet Gigabit High-Power PoE+ Injector,1 x 30 W Port, IEEE 802.3at/af Compliant, Plastic Housing
Stock: 0 units
Description
Description
Product overview
Provide both power and data to a Powered Device (PD) using existing Cat5 cable and this PoE Injector. The Intellinet Network Solutions Gigabit High-Power PoE+ Injector lets you connect your IEEE 802.3af/at-compliant product to a non-PoE LAN switch port. The PoE Injector can power and supply a network connection to a wireless access point, IP phone, network camera or any IEEE 802.3af/at-powered PD. This injector has an output power rating up to 30 watts. That's enough for even power-hungry PoE devices. Reduce Wiring Costs. There's no need to run AC power lines to get your PD set up and ready to do what it's supposed to. Simply connect the PoE Injector to the LAN switch port, and use the existing Cat5 cabling to deliver DC power as well as transfer data. Protect Your Equipment. Once DC power is connected to your networked equipment through the Cat5e/6 cabling, the Intellinet Network Solutions PoE Injector ensures that your products are protected from power problems like short circuits (short GND), current overloads and high voltages.
Why choose the Intellinet Gigabit High-Power PoE+ Injector,1 x 30 W Port...?
The Intellinet Gigabit High-Power PoE+ Injector,1 x 30 W Port, IEEE... is a poe adapters from Intellinet, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Ethernet interface type: Gigabit Ethernet; Ethernet LAN data rates: 10,100,1000 Mbit/s; Cable types supported: Cat5, Cat5e. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
| Cable types supported | Cat5, Cat5e |
| Maximum operating distance | 100 m |
| LED indicators | Yes |
| Power protection features | Over voltage, Overload, Short circuit |
| Ethernet LAN (RJ-45) ports | 2 |
| Output power | 30 W |
| Input voltage | 100-240 V |
| Input frequency | 50-60 Hz |
| Power consumption (max) | 35 W |
| Compliance certificates | CE, RoHS, Federal Communications Commission (FCC) |
| Certification | FCC, CE, UL |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating temperature (T-T) | -20 - 80 °F |
| Operating relative humidity (H-H) | 5 - 90% |
| Width | 67 mm |
| Depth | 136 mm |
| Height | 34 mm |
| Weight | 190 g |
| Manual | Yes |
| Harmonized System (HS) code | 85044095 |
| Brand | Intellinet |
| Manufacturer part number | 561518 |
| GTIN / UPC | ['0766623561518', '766623561518'] |
