Manhattan HDMI Splitter with downscaling 4-Port , 4K@60Hz, Displays output from x1 HDMI source to x4 HD displays (same output to four displays), Downscale button to adjust a 4K input signal into...
Stock: 0 units
Description
Description
Product overview
4K 4-Port HDMI Splitter with Downscaler - Easily split a single HDMI audio/video signal across four HDMI displays in 4K60 UHD and HDR. The compact Manhattan 4K@60Hz 4-Port HDMI Splitter splits a signal from a single HDMI source to four displays without distorting or degrading your video. Flexible solution with downscaling from 4K to 1080p for many A/V Applications. Ideal for trade shows, classrooms, video conferencing, presentations and retail applications, this 1x4 Splitter is a great choice for splitting and distributing a synchronous signal to four displays when source equipment is remotely stored in a secured room or cabinet. Cascade multiple units up to three levels to output HDMI video/audio to additional displays in widely distributed applications. A smart EDID management switch on the unit can downscale a 4K input signal to Full HD (or lower), making installations with older displays hassle-free. Easy installation and wide compatibility. Full compliance with HDMI 2.0 and HDCP 2.3 ensures that this 4-way Splitter can provide reliable performance. Quickly connect HDMI cables (not included) and the Micro-USB power cable to complete this affordable Ultra-High-Definition, 4K HDMI solution - no software/hardware configuration or complicated settings required. Full backward compatibility with 4K@30Hz and 1080p displays ensures that it will work with any HDMI source or destination device. This 4K Splitter is perfect for digital signage applications, where equipment may vary throughout your site. High-quality video. With transmission bandwidth up to 18 Gbps, this HDMI...
Why choose the Manhattan HDMI Splitter with downscaling 4-Port , 4K@60Hz...?
The Manhattan HDMI Splitter with downscaling 4-Port , 4K@60Hz, Displays... is a video splitters from Manhattan, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Video port type: HDMI; Video out: 4x HDMI; HDMI version: 2.0. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Workstations and open-plan offices
- Meeting rooms and huddle spaces
- Digital signage and reception areas
- Control rooms and monitoring desks
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Video port type | HDMI |
| Video out | 4x HDMI |
| HDMI version | 2.0 |
| Video ports quantity | 5 |
| Product colour | Black |
| Housing material | Plastic |
| Maximum resolution | 3840 x 2160 pixels |
| HD type | 4K Ultra HD |
| 3D | Yes |
| Maximum operating distance | 5 m |
| Colour depth | 36 bit |
| Bandwidth | 600 MHz |
| HDCP version | 2.3 |
| Extended display identification data (EDID) | Yes |
| High Dynamic Range (HDR) supported | Yes |
| Cable length | 0.8 m |
| Data transfer rate | 18 Gbit/s |
| HDCP | Yes |
| Plug and Play | Yes |
| Supported video modes | 480p, 576i, 720p, 1080i, 1080p |
| LED indicators | Yes |
| Dolby technologies | DTS-HD Master Audio, Dolby TrueHD |
| Number of displays supported | 4 |
| Downscaler | Yes |
| AC input voltage | 5 V |
| Power consumption (typical) | 5 W |
| USB powered | Yes |
| Width | 62 mm |
| Depth | 136 mm |
| Height | 15 mm |
| Weight | 87 g |
| Quantity per pack | 1 pc(s) |
| Package weight | 260 g |
| Package type | Box |
| Manual | Yes |
| Cables included | USB Type-A to Micro-USB Type-B |
| Packaging content | 4K@60Hz 4-Port HDMI Splitter with Downscaling Micro-USB to USB-A power cable, 0.8 m (2.6 ft.) Instructions |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -20 - 80 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Brand | Manhattan |
| Manufacturer part number | 208369 |
| GTIN / UPC | ['0766623208369', '766623208369'] |
