Intellinet 721080 patch panel 1U
Stock: 0 units
Description
Description
Product overview
LED Link Indicators, 19-inch Rackmount Panel, UTP, 180° Entry Punch-Down Blocks, for Solid Wire, Gold-plated Contacts, Black. Port Identifier 24-Port Cat6 UTP 1U Cat6 RJ45 Ethernet Patch Panel with LEDs - See Your Trace Status at a Glance. This rack-mount patch panel from Intellinet Network Solutions combines solid and reliable terminations with convenient status indicators. The built-in LEDs illuminate when connected to the Intellinet LED Port Identifier Tool allowing you to quickly identify the connected port. IEC 60297 / EIA 310-compliant and compatible with all standard 19 in. / 482.6 mm racks, our patch panel is designed to seamlessly integrate into your existing network setup. High-Quality Construction with UL 94 V-0 Flame Retardant Rating. Crafted with quality materials, this panel features 50 micro-inch gold-plated contacts, supporting 23 to 26 AWG solid wire. The SPCC steel bracket with antistatic powder coating ensure durability and reliability. It is ideal for advanced applications like HDBaseT and PoE up to IEEE802.3bt / PoE++ / 4PPoE / Ultra PoE. Enhancing safety measures, it has a flame-retardant rating in accordance with UL 94 V-0 standards, providing an extra layer of protection against fire hazards. Intellinet Port Identifier System. Experience the comprehensive LED Port Identification System by Intellinet, meticulously designed to streamline your networking endeavors. This system comprises of an LED port identifier tool alongside two variants of LED-equipped keystone jacks and this fully pre-loaded 24 Port Cat6 patch panel featuring intuitive LED...
Why choose the Intellinet 721080 patch panel 1U?
The Intellinet 721080 patch panel 1U is a patch panels from Intellinet, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Networking standards: IEEE 802.3bt; Ethernet interface type: 10 Gigabit Ethernet; Maximum data transfer rate: 10000 Mbit/s. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Networking standards | IEEE 802.3bt |
| Ethernet interface type | 10 Gigabit Ethernet |
| Maximum data transfer rate | 10000 Mbit/s |
| Ports quantity | 24 |
| Connector(s) | RJ-45 |
| Connector contacts plating | Gold |
| Cable types supported | Cat6 |
| Cable shielding | U/UTP (UTP) |
| AWG wire size | 23/26 |
| Product colour | Black |
| Material | Steel |
| Mounting | Rack mounting |
| Rack capacity | 1U |
| Input voltage | 1000/750 V |
| Power over Ethernet (PoE) | Yes |
| Compliance certificates | CE, REACH, RoHS, UKCA, UL |
| Certification | ANSI/TIA-568-D ISO/IEC 11801 IEC 60603-7-41 |
| Operating temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Doesn't contain | Cadmium, Lead, Mercury |
| Width | 482.6 mm |
| Height | 43.7 mm |
| Depth | 34 mm |
| Weight | 640 g |
| Quick start guide | Yes |
| Package weight | 740 g |
| Package type | Box |
| Quantity per pack | 1 pc(s) |
| Warranty period | 3 year(s) |
| Brand | Intellinet |
| Manufacturer part number | 721080 |
| GTIN / UPC | ['0766623721080', '766623721080'] |
