Intellinet Ultra Long Range Outdoor Fast Ethernet PoE+ Extender Kit Extends PoE up to 1000 m (3280 ft.), One PD Port up to 95 W, IEEE 802.3bt (4PPoE) Compatible, IP67 Waterproof and Dustproof, Set of...
Stock: 0 units
Description
Description
Product overview
Ultra Long Distance Power over Ethernet Extension / Repeater / Amplifier for a PoE range up to 1,000 m (3,280 ft.) - even in harsh outdoor conditions. The Intellinet Network Solutions Ultra Long Range Outdoor Fast Ethernet PoE+ Extender Kit adds up to 1,000 m (3,280 ft.) to the connection distance from a PoE source to an output device via Cat5e or Cat6 cable. It has an output power rating up to 30 watts, which is enough for many power-hungry PoE devices. Its high range and weatherproof housing is especially useful for outdoor IP surveillance camera deployments. This PoE repeater delivers up to 30 W at 100 Mbps over 300 m (984 ft.) or up to 15.4 W at 10 Mbps over 800 m (2625 ft.). Designed for Outdoor Use. This PoE+ extender offers the right power and data connector for longer-distance applications and suits a wide variety of environments. Its weatherproof IP67 (waterproof and dustproof) rating and a wide operating temperature range of -10 - 55°C (14 - 131°F) make it able to withstand harsh outdoor conditions. Power over Ethernet 802.3bt-compliant Input, 802.3at/af-compliant Output. Supporting the IEEE 802.3bt protocol with input power up to 95 W, this PoE+ Extender Kit provides up to 30 watts to a connected 802.3at-compliant device or 15 W to an 802.3af-compliant device, along with data up to Fast Ethernet speeds. Reduced Wiring Costs. This PoE+ Extender helps avoid the expense of running AC power lines to a wireless access point, network camera or IP phone. Simply connect the extender to the LAN switch port through existing Cat5e/6/6a cables to deliver DC power as well as...
Why choose the Intellinet Ultra Long Range Outdoor Fast Ethernet PoE+...?
The Intellinet Ultra Long Range Outdoor Fast Ethernet PoE+ Extender Kit... is a network extenders from Intellinet, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Cable types supported: Cat3, Cat4, Cat5, Cat5e, Cat6, Cat6a; Ethernet LAN data rates: 10,100 Mbit/s; Duplex system: Full. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Cable types supported | Cat3, Cat4, Cat5, Cat5e, Cat6, Cat6a |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Duplex system | Full |
| International Protection (IP) code | IP67 |
| Plug and Play | Yes |
| Cabling technology | 10/100 |
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Product colour | White |
| LED indicators | Yes |
| Power consumption (typical) | 0.4 W |
| Power consumption (max) | 0.7 W |
| Power over Ethernet (PoE) | Yes |
| Operating temperature (T-T) | -10 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Width | 29 mm |
| Depth | 157 mm |
| Height | 29 mm |
| Weight | 155 g |
| Manual | Yes |
| Package type | Box |
| Compliance certificates | CE, RoHS, UL |
| Brand | Intellinet |
| Manufacturer part number | 561952 |
| GTIN / UPC | ['0766623561952', '766623561952'] |
