StarTech.com MSA Compliant SFP+ Transceiver Module - 10GBASE-BX~MSA Uncoded SFP+ Transceiver Module - 10GBASE-BX - 10 GbE Gigabit Ethernet BiDi Fiber (SMF)
Stock: 34 units
StarTech.com MSA Compliant SFP+ Transceiver Module - 10GBASE-BX~MSA...
Description
Description
Product overview
10 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty The SFP10GBBXUST is an MSA compliant upstream fiber SFP transceiver which pairs with StarTech.com's SFP10GBBXDST. They are designed, programmed and tested to work with 10GBASE-BX compatible MSA switches and routers. The SFP+ transceiver module supports a maximum distance of up to 10 km (6.2 mi) and delivers dependable 10 GbE connectivity over fiber cabling. Technical Specifications: • Wavelength: 1270nmTx/1330nmRx • Maximum Data Transfer Rate: 10 Gbps • Type: Single Mode Fiber • Connection Type: LC Connector • Maximum Transfer Distance: 10 km (6.2 mi) • Power Consumption: Less than 1 Watt • DDM: Yes This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions. StarTech.com SFPs All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance. The StarTech.com Advantage
Why choose the StarTech.com MSA Compliant SFP+ Transceiver Module...?
The StarTech.com MSA Compliant SFP+ Transceiver Module - 10GBASE-BX~MSA... is a network transceiver modules from StarTech.com, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — SFP transceiver type: Fiber optic; Maximum data transfer rate: 10000 Mbit/s; Interface type: SFP+. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 10000 Mbit/s |
| Interface type | SFP+ |
| Single-mode fiber (SMF) supported | Yes |
| Fiber optic connector | LC |
| SFP transceiver standard | BX |
| Maximum transfer distance | 10000 m |
| Tx wavelength (min) | 1270 nm |
| Rx wavelength (min) | 1330 nm |
| Networking standards | IEEE 802.3ae |
| Duplex system | Full |
| Digital Diagnostics Monitoring (DDM) | Yes |
| Wavelength-division multiplexing (WDM) | Yes |
| Product colour | Silver |
| Housing material | Aluminium |
| Hot-Plug support | Yes |
| Compliance certificates | RoHS |
| Certification | CE, FCC, UR |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Width | 13.9 mm |
| Depth | 58.4 mm |
| Height | 12.6 mm |
| Weight | 24 g |
| Quantity per pack | 1 pc(s) |
| Package width | 90 mm |
| Package depth | 115 mm |
| Package height | 30 mm |
| Package weight | 54 g |
| Master (outer) case width | 315 mm |
| Master (outer) case length | 405 mm |
| Harmonized System (HS) code | 85369010 |
| Master (outer) case height | 315 mm |
| Products per master (outer) case | 80 pc(s) |
| Country of origin | China |
| Brand | StarTech.com |
| Manufacturer part number | SFP10GBBXUST |
| GTIN / UPC | ['0065030873406', '065030873406'] |
