StarTech.com 1-Port 10Gbps PoE++ Injector, 90W, 2.5/5/10G Ethernet/10/100/1000M, PoE++ (802.3af/at/bt), Wall Mountable, Unmanaged Inline Power Over Ethernet, TAA
Stock: 2 units
StarTech.com 1-Port 10Gbps PoE++ Injector, 90W, 2.5/5/10G Ethernet/...
Description
Description
Product overview
Supply power and data to a PoE device over standard Ethernet cabling This 1-port multi-speed PoE++ Injector serves as a Power Sourcing Equipment (PSE) device and enables Ethernet speeds of 10/100 Mbps/1000Mbps and 1/2.5/5/10Gbps. This TAA-compliant mid-span inline injector can transmit network data and power up to 328ft (100m) for single Powered Devices (PD). Versatile PoE Injector Single port PoE+ injector supports the IEEE 802.3af/at & 802.3bt PSE standards, and delivers up to 90W output (56V, 1.7A). Connect a remote PoE device to a network at a location where there is no power source, but an Ethernet cable already exists. This includes access points, IP cameras, VoIP phone systems, IPTV and access controls. The flexible design of the PoE injector allows for either desktop or surface-mount use. Streamlined Cable Management With integrated wall-mounting ears, this Gigabit PoE++ injector offers convenient and versatile installation options. All Ethernet cables can be routed from one side of the unit for efficient and organized cable management. The compact design (4x2.3x1.3-inch / 100x58.4x33.4mm) ensures straightforward integration into existing network infrastructure, saving space and time during installation.
Why choose the StarTech.com 1-Port 10Gbps PoE++ Injector, 90W, 2.5/5/10G...?
The StarTech.com 1-Port 10Gbps PoE++ Injector, 90W, 2.5/5/10G... is a poe adapters from StarTech.com, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Ethernet LAN data rates: 10000 Mbit/s; Cabling technology: 1000/10000; Power over Ethernet (PoE): Yes. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Ethernet interface type | 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 10000 Mbit/s |
| Cabling technology | 1000/10000 |
| Power over Ethernet (PoE) | Yes |
| Networking standards | IEEE 802.3ab, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3u |
| Auto MDI/MDI-X | Yes |
| Chipset | SkyWorks - Si3471A-A01 |
| Product colour | Black |
| Housing material | Plastic |
| Wall mountable | Yes |
| Maximum operating distance | 100 m |
| LED indicators | Yes |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Power protection features | Over current, Over voltage, Short circuit |
| Auto-negotiation | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| AC adapter input voltage | 100 - 240 V |
| Input current | 1.5 A |
| AC adapter output voltage | 56 V |
| Output current | 1.7 A |
| Total Power over Ethernet (PoE) budget | 90 W |
| Suitable for use in country/location | United States |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -30 - 80 °C |
| Width | 64 mm |
| Depth | 170 mm |
| Height | 34 mm |
| Weight | 350 g |
| Power cord included | Yes |
| Quick installation guide | Yes |
| Package width | 212 mm |
| Package depth | 125 mm |
| Package height | 52 mm |
| Package weight | 600 g |
| Master (outer) case width | 286 mm |
| Master (outer) case length | 522 mm |
| Brand | StarTech.com |
| Manufacturer part number | AF41XC-POE-INJECTOR |
| GTIN / UPC | ['0065030902212', '065030902212'] |
