ATEN 4 x 2 True 4K Presentation Matrix Switch
Stock: 0 units
Description
Description
Product overview
The VP1421 is a multi-in-one presentation switch that integrates a video matrix, True 4K scaler, HDBaseT extender, audio DSP, and analog-to-digital converter functions into a single compact enclosure, ideal for meeting rooms and educational spaces. True 4K, HDR Visual Clarity Supports resolutions up to 4096 x 2160 @ 60Hz (4:4:4) and HDR to deliver vivid content in every presentation. Smooth AV Switching Scaled to Perfection Connect up to 4 sources (1 HDBaseT, 2 HDMI, 1 VGA), smoothly switch between them and display contents scaled perfectly to True 4K and 1080p simultaneously. HDBaseT Extended Transmission over One Cable Simplifies cabling and transmits AV, power, and bi-directional RS-232 and IR control signals up to 140m via Cat 6/6a or ATEN 2L-2910 Cat 6 cables (applying both HDBaseT input and output ports). Built-in Advanced Audio DSP Supports microphone input with selectable 48V Phantom Power and allows microphone input to be mixed with program audio and embedded into display output while automatically reducing program audio to enhance speech audibility. Flexible Audio Embedding/De-Embedding Supports stereo audio embedding into HDMI output or separation to Audio Line Out and Optical Audio Out. Extract HDMI and HDBaseT audio to different audio outputs as well to ease adaptation to you preferred audio setup. Versatile Control, Streamlined Operations Control via front-panel pushbuttons, IR remote, web-based GUI and any control interface via RS-232, Ethernet, and Contact Closure to streamline your operations.
Why choose the ATEN 4 x 2 True 4K Presentation Matrix Switch?
The ATEN 4 x 2 True 4K Presentation Matrix Switch is a matrix switchers from ATEN, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Product type: Scaling matrix switcher; Maximum resolution: 4096 x 2160 pixels; HDCP: Yes. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Product type | Scaling matrix switcher |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| HDCP version | 2.2 |
| 3D | Yes |
| High Dynamic Range (HDR) supported | Yes |
| Extended display identification data (EDID) | Yes |
| Housing colour | Black |
| Housing material | Metal |
| Control type | Buttons, Rotary |
| On/off switch | Yes |
| Remote control included | Yes |
| HDMI input ports quantity | 2 |
| HDMI output ports quantity | 1 |
| VGA (D-Sub) input ports | 1 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Remote (IR) output | 1 |
| Remote (IR) input | 1 |
| DC-in jack | Yes |
| Power consumption (typical) | 14.93 W |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
| Heat dissipation | 110 BTU/h |
| Products per master (outer) case | 3 pc(s) |
| Master (outer) case gross weight | 7.25 kg |
| Master (outer) case length | 427 mm |
| Master (outer) case width | 370 mm |
| Master (outer) case height | 232 mm |
| Master (outer) case net weight | 4.74 kg |
| Harmonized System (HS) code | 85299097 |
| Width | 170.1 mm |
| Depth | 200 mm |
| Height | 44 mm |
| Weight | 1.58 kg |
| Package width | 207 mm |
| Package depth | 414 mm |
| Brand | ATEN |
| Manufacturer part number | VP1421-AT-G |
| GTIN / UPC | ['4719264649158', '0672792010880', '672792010880'] |
