INJECTEUR POWER OVER ETHERNET/POE
Stock: 0 units
Description
Description
Product overview
Reduce costs by using existing Cat5 cable to provide both power and data. The INTELLINET NETWORK SOLUTIONS Power over Ethernet Injector allows you to connect your IEEE 802.3af-compliant products to a non-PoE LAN switch port. The injector can be used to connect a wireless access point, IP phone, network camera or any IEEE 802.3af powered device (PD) to a switch. Reduce Wiring Costs. No need to run AC power lines for your wireless access point, network camera or IP phone. Simply connect the PoE Injector to the LAN switch port, and use the existing Cat5 cabling to deliver DC power as well as transfer data. Preserve Existing Investments. Does your existing LAN switch not support the new IEEE 802.3af PoE standard? Well, don't let that stop you from realising the benefits of delivering DC power over the existing Cat5 Ethernet cabling. Use the Model 503389 PoE Injector until you are able to upgrade your LAN switch to a model that supports the IEEE 802.3af PoE standard. Protect Your Equipment. Now that you are running DC power to your networked equipment through the Cat5 cabling, you need to be sure that the products are protected from power problems. The PoE Injector was designed to protect equipment from short circuits (short GRND), current overloads (over 450 mA) and high voltages (voltage exceeding 52 V).
Why choose the Intellinet Power over Ethernet (PoE) Injector, 1 Port, 48 V...?
The Intellinet Power over Ethernet (PoE) Injector, 1 Port, 48 V DC, IEEE... is a poe adapters from Intellinet, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Ethernet interface type: Fast Ethernet; Ethernet LAN data rates: 10,100 Mbit/s; Power over Ethernet (PoE): Yes. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Power over Ethernet (PoE) | Yes |
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3u |
| Cable types supported | Cat5 |
| Product colour | Black |
| Safety | SCP |
| Power protection features | Over voltage, Overload, Short circuit |
| Ethernet LAN (RJ-45) ports | 2 |
| Power over Ethernet (PoE) voltage | 52 V |
| Power requirements | 15.4 W |
| AC adapter frequency | 50/60 Hz |
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
| Input current | 0.45 A |
| AC adapter output voltage | 48 V |
| Output current | 0.35 A |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Certification | FCC Class B, Part 15, CE 89/336/EEC, UKCA, NDAA |
| Operating temperature (T-T) | 0 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -20 - 85 °C |
| Size (imperial) | 5.08 cm (2") " |
| Width | 50 mm |
| Depth | 120 mm |
| Height | 35 mm |
| Weight | 140 g |
| Number of products included | 1 pc(s) |
| Manual | Yes |
| Harmonized System (HS) code | 85044095 |
| Brand | Intellinet |
| Manufacturer part number | 524179 |
| GTIN / UPC | ['7666235241798', '5711045416309', '0766623524179', '766623524179', '0743172986443', '743172986443', '0100177417493', '100177417493'] |
