Câble Patch - Paire Torsadée Blindée Non Écranée (U/FTP) - Mâle Gauche - Mâle D
Stock: 0 units
Description
Description
Product overview
Cat 8 Ethernet Cable, 10 pcs - 40G, 2000 MHz LAN patch cord, ultra-thin - future-proof high-end connections in data centers and more. Establish your high-performance network connections, especially for Top of Rack (ToR) and Middle of Row (MoR) installations in data centers, with this Cat8.1 U/FTP Network Patch Cable from Intellinet Network Solutions. Our Cat8 Ethernet cable speeds can reach as high as 40 Gbps, with frequencies supported up to 2 GHz. It's a clear winner in achieving future-proof network connections. Strong, yet slim, space-saving design. This stranded-copper Cat8 cable offers all the benefits of a standard Cat8.1 network cable but with a diameter that's considerably smaller. In dense cable installations, the cable creates a tidier and more-organized look, and its thinner size helps promote better air circulation to equipment in a network cabinet. The cable's reduced size also means it is more flexible, which makes it a perfect choice for installation around corners and in tight-space cable runs. Aluminum foil shielding for good signal quality and low noise. This Cat8 patch cable is ideal for ultra-high performance network applications up to 25GBase-T and 40GBase-T with PoE applications up to IEEE802.3bt / PoE++ / 4PPoE / Ultra PoE. Its U/FTP design has the inner cable wrapped in an overall aluminum braid. The result is great data transfer because it helps prevent interference such as near-end crosstalk (NEXT) if cables run parallel to each other. Pure copper cable with gold-plated contacts for perfect conductivity. As opposed to other cables that are...
Why choose the Intellinet 745543 networking cable Red 1.5 m Cat8.1 U/FTP...?
The Intellinet 745543 networking cable Red 1.5 m Cat8.1 U/FTP (STP) is a networking cables from Intellinet, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Product colour: Red; Cable length: 1.5 m; Cable standard: Cat8.1. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Product colour | Red |
| Cable length | 1.5 m |
| Cable standard | Cat8.1 |
| Cable shielding | U/FTP (STP) |
| Connector 1 | RJ-45 |
| Connector 2 | RJ-45 |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Connector contacts plating | Gold |
| Connector shielding | Yes |
| Connector shield material | Aluminium |
| Jacket material | Polyvinyl chloride (PVC) |
| Cable shape | Round |
| Conductor type | Stranded |
| Conductor material | Copper |
| Cabling technology | 40GBase-T |
| Ethernet interface type | 25 Gigabit Ethernet, 40 Gigabit Ethernet |
| Networking standards | IEEE 802.3bt |
| AWG wire size | 30 |
| Data transfer rate | 40000 Mbit/s |
| Frequency | 2000 MHz |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | PoE++ (4PPoE) |
| Snagless cable boot | Yes |
| Plug and Play | Yes |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Doesn't contain | Cadmium, Lead, Mercury |
| Compliance certificates | CE, REACH, RoHS, UL |
| Certification | ISO/IEC 11801 EN 50173-1 ANSI/TIA-568.2-D |
| Outer diameter | 4.8 mm |
| Quantity per pack | 10 pc(s) |
| Package type | Bag |
| Brand | Intellinet |
| Manufacturer part number | 745543 |
| GTIN / UPC | ['0766623745543', '766623745543'] |
Frequently asked questions
How long does delivery take?
Orders are processed within 24 hours. Once your tracking number is issued, delivery takes 24 to 72 hours to major centres in the main provinces, and 3 to 8 business days to remote regions. We ship with FedEx, DHL, UPS, Canada Post and Purolator.
Is this product covered by a warranty?
Yes. This item carries the manufacturer's warranty. See our Refund Policy for return windows and conditions, or contact us and we will walk you through the process.
Can I get volume pricing?
Yes. Volume discounts apply automatically as quantity increases, and our team can quote larger projects directly — reach us by phone, WhatsApp or email.
Do the specifications on this page come from the manufacturer?
They do. Product data on this page is sourced from the manufacturer's own catalogue, not rewritten from a distributor summary.
