QNAP QSW-M2130P-2C2S26T, COMMUTATEUR DE GESTION, 24X 2.5GBE RJ45 POE + 2X 10GBE RJ45
Stock: 0 units
Description
Description
Product overview
QSW-M2130P-2C2S26T. L2 Managed Switch with 90-watt 10GbE and 45-watt 2.5GbE PoE++. QSW-M2130P-2C2S26T is a next-generation L2 managed switch featuring 24 x 2.5GbE Base-T ports, 2 x 10GbE SFP+, 2 x 10GbE Base-T, and 2 x 10GbE Combo ports, integrating high-speed connectivity and PoE in one device. The multi-Gigabit port design makes it ideal for deployment as both an access and aggregation switch, supporting Wi-Fi 6/6E/7 APs, IP surveillance, and various powered devices. With support for VLAN, QoS, LACP, and ACL, along with the intuitive QSS (QNAP Switch System), it enables businesses to build a scalable, efficient, and easy-to-manage network infrastructure. The QSW-M2130P-2C2S26T is made in Taiwan (MIT), providing a high-quality and reliable networking solution.
Why choose the QNAP QSW-M2130P-2C2S26T network switch Managed L2 2.5G...?
The QNAP QSW-M2130P-2C2S26T network switch Managed L2 2.5G Ethernet... is a network switches from QNAP, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Switch type: Managed; Switch layer: L2; Web-based management: Yes. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Web-based management | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 26 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| 2.5G Ethernet (copper) ports quantity | 24 |
| 10G Ethernet (copper) ports quantity | 2 |
| Combo SFP ports quantity | 2 |
| SFP+ module slots quantity | 2 |
| Console port | RJ-45 |
| Power connector | AC-in jack |
| Networking standards | IEEE 802.3bz, IEEE 802.3an, IEEE 802.3ae, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3ad, IEEE 802.1p, IEEE 802.3az |
| 10G support | Yes |
| Switching capacity | 240 Gbit/s |
| Throughput | 120 Gbit/s |
| MAC address table | 32000 entries |
| Jumbo frames support | Yes |
| Jumbo frames | 12000 |
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Yes |
| DIN rail mounting | Yes |
| Number of fans | 1 fan(s) |
| Noise level | 28 dB |
| Power source | AC |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 70 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 16 |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 12 |
| Total Power over Ethernet (PoE) budget | 375 W |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Width | 440 mm |
| Depth | 205 mm |
| Height | 44 mm |
| Weight | 3.54 kg |
| Brand | QNAP |
| Manufacturer part number | QSW-M2130P-2C2S26T |
| GTIN / UPC | ['4711103091562', '0885022033874', '885022033874'] |
