StarTech.com 3-Port PCI Express USB 3.0 Card + Gigabit Ethernet - 5Gbps - TAA
Stock: 284 units
StarTech.com 3-Port PCI Express USB 3.0 Card + Gigabit Ethernet - 5...
Description
Description
Product overview
Running low on expansion slots? Merge USB 3.0 (USB 3.2 Gen 1) and GbE into a single PCIe combo card This PCIe USB 3.2 Gen 1 card couples your peripheral and network connections into a single, scalable solution. By combining three USB 3.2 Gen 1 ports and one RJ45 port onto a single card, you only need a single PCIe slot for installation, which lets you free up space for other add-ons or upgrades and get more out of your desktop or server. Combo-card convenience and cost-savings If you have separate cards for your USB and network connections, this versatile card overcomes the aggravation of running out of PCIe slots while helping to reduce clutter inside your PC. This dual-purpose card is perfect for building or upgrading your computer. It helps you save money by avoiding the additional costs of purchasing separate USB 3.2 Gen 1 and Gigabit Ethernet adapters. Flexible install options and legacy device support You can rest assured this card will fit in your small form-factor system, if needed. It features a dual-profile design that makes it easy to install in either standard or low-profile cases. The combo card makes it easy to connect peripherals such as your external hard drives or mobile devices. Plus, it’s backward compatible with USB 2.0 and 1.x, so you won’t have to replace all of your existing USB devices. Gigabit connectivity and network management Functioning as a network adapter, the card delivers wired network access in locations where Wi-Fi® is unavailable or unreliable. Support for advanced features such as jumbo frames and VLAN tagging means you can optimize...
Why choose the StarTech.com 3-Port PCI Express USB 3.0 Card + Gigabit...?
The StarTech.com 3-Port PCI Express USB 3.0 Card + Gigabit Ethernet... is a network cards from StarTech.com, selected for Canadian businesses that need reliable, specification-accurate hardware. Key figures at a glance — Connectivity technology: Wired; Host interface: PCI Express; Interface: Ethernet. Every listing at FullOffice.ca is built from verified manufacturer data, so what you read here is what ships to you.
Highlights
Key benefits
- ✔ Verified manufacturer specifications — no guesswork before you buy
- ✔ Ships from Canada: 24 to 72 hours to major centres, 3 to 8 business days elsewhere
- ✔ Volume pricing available for business and reseller accounts
- ✔ Support by phone, WhatsApp or email before and after your purchase
Recommended use cases
- Structured cabling and network closets
- Data centre and server room links
- Branch office connectivity
- Campus and building-to-building runs
Recommended industries
Specifications
| Specification | Detail |
|---|---|
| Connectivity technology | Wired |
| Host interface | PCI Express |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 3 |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| PCI version | 2.0 |
| PCI Card form factor | Full-height (low-profile) |
| Maximum data transfer rate | 5000 Mbit/s |
| Networking standards | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000BaseT(X) |
| Wake-on-LAN ready | Yes |
| Auto MDIX IEEE | Yes |
| Full duplex | Yes |
| Jumbo frames support | Yes |
| Auto-negotiation | Yes |
| Jumbo frames | 9000 |
| VLAN tagging | Yes |
| Product colour | Metallic, Red |
| Internal | Yes |
| Chipset | Renesas / NEC - µPD720201, Realtek - RTL8153 |
| LED indicators | Activity, Link |
| Mean time between failures (MTBF) | 1920042 h |
| Certification | CE, FCC |
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64... |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012 |
| Operating temperature (T-T) | 5 - 50 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Width | 18 mm |
| Depth | 77 mm |
| Height | 120 mm |
| Weight | 60 g |
| Drivers included | Yes |
| Quantity per pack | 1 pc(s) |
| Package width | 143 mm |
| Package depth | 174 mm |
| Brand | StarTech.com |
| Manufacturer part number | PEXUSB3S3GE |
| GTIN / UPC | ['0065030860796', '065030860796'] |
